TYPE550X 型是一种电子压力调节器，可将可变信号（电流或电压）转换为成比例的气动输出。其紧凑的外壳、可访问的端口和易于调整的端口为空间受限的应用提供了理想的解决方案。这种经济型仪器为执行器、阀门、定位器和其他最终控制元件提供精确的气压调节。一体式体积增压器提供高流量，提高关键应用中的控制速度。常用型号|TYPE500-BC|TYPE500-AC|TYPE500-BE

Type 550X Miniature I/P,E/PTransducer Accurate and economical electronic pressure control The Type 550X is an electronic pressure regulator that converts a variable signal (current or voltage) to a proportional pneumatic output. Its compact housing, accessible ports and easy adjustments provide an ideal answer to applications that are space-constrained. This economical instrument provides precision air pressure regulation to actuators, valves, positioners and other final control elements. An integral volume booster provides high flow capacity, increasing control speed in critical applications. Features •Compact Size Great for high density mounting •Easy Wiring Conduit, terminal block, M12 or DIN 43650 connections •Mounting Options Wall, panel, DIN rail, pipe or manifold mounted (Type-925) •Input/Output Ports on Front and Back Provides flexible pneumatic connections •External Zero and SpanAdjustments Convenient field calibration •Field Reversible Capability Output is inversely proportional to input signal •IntrinsicSafetyApprovals Factory Mutual (FM) Canadian StandardsAssoc. ATEX (option) (CSA) 8 Functional Specifications Standard Range High Output Range Zero-Based Range Inputs 4-20 mA 0-5 VDC, 0-10 VDC, 1-5 VDC, 1-9 VDC Outputs psig 3-15 3-27 6-30 2-60 3-120 0-30 0-60 0-120 (BAR) (0.2-1.0) (0.2-1.8) (0.4-2.0) (0.14-4.0) (0.2-8.0) (0.0-2.0) (0.0-4.0) (
